Standalone Waterproof RFID Access Control Reader
IP 67 Based
Contact us
D8-RE
♦ Stand-Alone Proximity Card Reader.
♦ Use in small businesses, homes, parking structures, apartments, and other locations.
♦ Sealed and weatherproof (IP67). Mounts easily to interior and exterior walls.
♦ Attractive tri-color wave-shaped LED status bar indicates proximity reader's mode and status.
♦ Output relay for either timed (1 to 180 seconds) or "Toggle" mode.
♦ Buzzer is programmable for audible confirmation or silent mode.
♦ Up to 100 user cards can be programmed.
♦ User cards easily deleted. Delete a single card, or all cards.
♦ Up to 5 "Master" cards can be programmed.
|
Model |
D8-RE |
|
Display |
No LCD Display |
|
Speaker |
Programmable audio buzzer for audible confirmation or silent mode |
|
Card Capacity |
100 User cards, 5 Master cards |
|
Log capacity |
N/A |
|
Access Mode |
Card only |
|
Identification |
Identification speed ≤ 20ms |
|
Max. Read Distance |
3-5cm |
|
Transmit Frequency |
125Khz(Mifare card reader is optional) |
|
Outputs |
1 relay (Com, N.O., N.C.) |
|
Contact Rating |
1A@30V |
|
Relay Time Delay |
1~180secs./Toggle mode |
|
Enclosure Rating |
IP67 |
|
Environment |
Operation temperature: -20℃ ~ 70℃ Operation humidity: 20% ~ 80% |
|
Power Supply |
110/220VAC ~ 12VDC(PS-3A is optional item) |
|
Machine Size |
95(L)*45(W)*16(H)mm |
|
Standand Function |
Standalone, 1 door controller, built-in realy, IP67 |
